Overview

XMLUtils is a Dyalog APL namespace containing utilities designed to:

  • Convert HTML to XHTML. XHTML is essentially HTML that is rewritten to follow the stricter rules of XML. XHTML can be processed by Dyalog APL's ⎕XML system function to produce a matrix form of the content. This matrix form lends itself to easier manipulation in APL.
  • Manipulate matrix form XML data. There are utilities to search, select, insert, replace, and delete elements in the XML matrix data.

Note

While XMLUtils itself is ⎕IO and ⎕ML insensitive, the examples in this documentation assume an environment of (⎕IO ⎕ML)←1.

Obtaining XMLUtils

XMLUtils is a single namespace contained in a single APL source file. There are several ways to obtain XMLUtils.

  • Released versions are available on GitHub.
  • XMLUtils is also available as a Tatin package: bpbecker-XMLUtils.
  • The latest "pre-release" version, if any, can be found in the master branch of https://github.com/BPBecker/XMLUtils
  • You can also use the ]get user command to load XMLUtils into your active workspace.
      ]get https://github.com/bpbecker/XMLUtils/raw/refs/heads/master/Source/XMLUtils.apln

Motivation

XMLUtils started as a simple project in a namespace named xhtml. I occasionally found data in web pages that I wanted to import into my workspace for further processing. Because HTML has a "looser" rule set than XHTML, a lot of times I couldn't simply run the HTML through ⎕XML. And thus was born HTMLtoXHTML - a utility that attempts to convert HTML, even malformed HTML, into XHTML and then use ⎕XML to return the data in matrix form.

Once I've got the XML matrix, what can I do with it? That's where the other part of XMLUtils comes in - to search and select

For example, let's suppose I wanted to find all the stylesheets that are linked to the Dyalog.com home page. (Note that the examples below reflect the content of the Dyalog home page at the time of this writing - it may change.)

First, I'll use HttpCommand to grab the HTML for the page

      ]load HttpCommand
      html←(HttpCommand.Get 'dyalog.com').Data
      50↑html
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Trans

Next, I'll convert it to XML using HTMLtoXHTML

      ≢xml←XMLUtils.HTMLtoXHTML html
308

Now I'll Xfind to find all of the <link> elements that have a rel=stylesheet attribute

      +/matches←xml XMLUtils.Xfind '//link//rel/stylesheet'
4

I can use Xsel to select those elements.

      ≢elements←xml XMLUtils.Xsel matches
4

Finally, I can get the URLs for all of the stylesheets using the href attribute.

      ⍪urls←elements XMLUtils.Xattr 'href'
  https://fonts.googleapis.com/css2?family=Exo+2:wght@400;700&display=swap
  //cdn.dyalog.com/css/apl385.css
  /uploads/css/jquery.fancybox.css
  https://www.dyalog.com/tmp/cache/stylesheet_combined_46f9f0f9723b06cff2425d65f29f50ab.css

Combining it all...

      urls←(xml XMLUtils.Xsel xml XMLUtils.Xfind'//link//rel/stylesheet')XMLUtils.Xattr 'href'
